Forensic Investigation setup script
A small script to quickly setup a folder structure and gather artifacts from a disk.
To strengthen my Windows forensics skills, I recently completed the Practical Windows Forensics course by Markus Schober from Blue Cape Security, offered through TCM Security. This practical course is focused on analyzing Windows-based attacks through disk images, artifact extraction, malware detection, and evidence handling.
Case Structure and Workflow
The course uses a acquired disk image, mounted to the investigation system (with temporary write access) as the investigation source. Artifacts are collected into a structured case directory, grouped into subfolders (e.g., Registry, EventLogs, Execution).
I found this folder structure extremely useful and decided to automate the setup for future investigations.
Before starting the script the image has to be mounted.
Automating
To save time and reduce manual work, I wrote a batch script that creates the folder structure, collects the artifacts using tools like KAPE, RegRipper, MFTECmd, etc and stores everything in the correct location.
Script
Below is the batch script. It prompts for the investigation name and the disk letter of the mounted image. During the collections it prompts for the accountname of the users on the disk to collect the user artifacts. It handles folder creation, artifact collection, and basic triage parsing.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
@echo off
set /p investigation="Enter investigation name: "
set /p disk="Enter Disk containing evidence: "
:: Create folder tree
echo Creating folder tree
MkDir "C:\Cases\%investigation%\Analysis\"
MkDir "C:\Cases\%investigation%\Analysis\User_Activities\"
MkDir "C:\Cases\%investigation%\Analysis\User_Activities\Cache\"
MkDir "C:\Cases\%investigation%\Analysis\User_Activities\Link_Files\"
MkDir "C:\Cases\%investigation%\Analysis\User_Activities\Jump_Lists\"
MkDir "C:\Cases\%investigation%\Analysis\Host_Information\"
MkDir "C:\Cases\%investigation%\Analysis\EventLogs\"
MkDir "C:\Cases\%investigation%\Analysis\EventLogs\Hayabusa\"
MkDir "C:\Cases\%investigation%\Analysis\Execution\"
MkDir "C:\Cases\%investigation%\Analysis\Execution\Amcache\"
MkDir "C:\Cases\%investigation%\Analysis\Execution\Prefetch\"
MkDir "C:\Cases\%investigation%\Analysis\Exports\"
MkDir "C:\Cases\%investigation%\Analysis\Memory\"
MkDir "C:\Cases\%investigation%\Analysis\Memory\dll\"
MkDir "C:\Cases\%investigation%\Analysis\NTFS\"
MkDir "C:\Cases\%investigation%\Analysis\NTFS\MFT\"
MkDir "C:\Cases\%investigation%\Analysis\Registry\"
MkDir "C:\Cases\%investigation%\Analysis\Timeline\"
MkDir "C:\Cases\%investigation%\Evidence\"
MkDir "C:\Cases\%investigation%\Kape\"
:: Run KAPE
echo Run KAPE
cd "C:\Tools\KAPE\"
.\kape.exe --tsource %disk%: --tdest C:\Cases\%investigation%\Kape --tflush --target KapeTriage --gui
::.\kape.exe --tsource %disk%: --tdest C:\Cases\%investigation%\Kape --tflush --target KapeTriage --msource C:\Cases\%investigation%\Kape --mdest C:\Cases\%investigation%\Analysis\Modules --mflush --module !EZParser --gui
:: Copy registry hives from evidence
echo Copy registry hives
xcopy "C:\Cases\%investigation%\Kape\%disk%\Windows\System32\config\" "C:\Cases\%investigation%\Analysis\Registry\" /H
:: Show Users on disk
cd /d "%disk%:\Users\"
dir /b /o:n /ad-h
set /p useraccount="Name of user account in evidence: "
:: User hives
echo Copy User hives
cd /d "C:\"
xcopy "C:\Cases\%investigation%\Kape\%disk%\Users\%useraccount%\AppData\Local\Microsoft\Windows\UsrClass.dat" "C:\Cases\%investigation%\Analysis\Registry\" /H
xcopy "C:\Cases\%investigation%\Kape\%disk%\Users\%useraccount%\NTUSER.dat" "C:\Cases\%investigation%\Analysis\Registry\" /H
:: RegRipper
echo Run RegRipper
cd "C:\Cases\%investigation%\Analysis\Registry\"
attrib -h UsrClass.dat
attrib -h NTUSER.dat
for /r %%i in (*) do (C:\Tools\RegRipper3.0-master\rip.exe -r %%i -a > %%i.txt)
:: Acquire device information
cd "C:\Cases\%investigation%\Analysis\Registry\"
:: Hostname
C:\Tools\RegRipper3.0-master\rip.exe -r "SYSTEM" -p compname | findstr "ComputerName\ \ \ \ =" | findstr "ComputerName" > "C:\Cases\%investigation%\Analysis\Host_Information\Hostname.txt"
:: Windows version
C:\Tools\RegRipper3.0-master\rip.exe -r "SOFTWARE" -p winver > "C:\Cases\%investigation%\Analysis\Host_Information\WindowsVersion.txt"
:: Defender options
C:\Tools\RegRipper3.0-master\rip.exe -r "SOFTWARE" -p defender > "C:\Cases\%investigation%\Analysis\Host_Information\DefenderSettings.txt"
:: Timezone
C:\Tools\RegRipper3.0-master\rip.exe -r "SYSTEM" -p timezone > "C:\Cases\%investigation%\Analysis\Host_Information\Timezone.txt"
:: Profile List
C:\Tools\RegRipper3.0-master\rip.exe -r "SOFTWARE" -p profilelist > "C:\Cases\%investigation%\Analysis\Host_Information\Profilelist.txt"
:: Network Information
C:\Tools\RegRipper3.0-master\rip.exe -r "SYSTEM" -p nic2 > "C:\Cases\%investigation%\Analysis\Host_Information\NetworkInformation.txt"
:: Shutdown time
C:\Tools\RegRipper3.0-master\rip.exe -r "SYSTEM" -p shutdown > "C:\Cases\%investigation%\Analysis\Host_Information\ShutdownTime.txt
:: MFTECmd
echo Run MFTECmd to parse MasterFileTable
cd "C:\Tools\EZTools\"
MFTECmd.exe -f "C:\Cases\%investigation%\Kape\%disk%\$MFT" --csv "C:\Cases\%investigation%\Analysis\NTFS\MFT" --csvf MFT.csv
echo Run MFTECmd to parse Journal
MFTECmd.exe -f "C:\Cases\%investigation%\Kape\%disk%\$Extend\$J" -m "C:\Cases\%investigation%\Kape\%disk%\$MFT" --csv "C:\Cases\%investigation%\Analysis\NTFS"
:: AppCompatCacheParser
echo Run AppCompatCacheParser
AppCompatCacheParser.exe -f "C:\Cases\%investigation%\Analysis\Registry\SYSTEM" --csv "C:\Cases\%investigation%\Analysis\Execution"
:: AmcacheParser
echo Run AmcacheParser
AmcacheParser.exe -f "C:\Cases\%investigation%\Kape\%disk%\Windows\AppCompat\Programs\Amcache.hve" --csv "C:\Cases\%investigation%\Analysis\Execution\Amcache"
:: PECmd
echo Run PECmd
PECmd.exe -d "C:\Cases\%investigation%\Kape\%disk%\Windows\prefetch" --csv "C:\Cases\%investigation%\Analysis\Execution\Prefetch"
::EvtxECmd
echo Run EvtxECmd
cd "C:\Tools\EZTools\EvtxeCmd"
EvtxECmd.exe -d "C:\Cases\%investigation%\Kape\%disk%\Windows\System32\winevt\logs" --csv "C:\Cases\%investigation%\Analysis\EventLogs"
::Hayabusa
echo Run Hayabusa
cd "C:\Tools\hayabusa"
hayabusa.exe csv-timeline -m med --RFC-3339 --quiet -U -d "C:\Cases\%investigation%\Kape\%disk%\Windows\System32\winevt\logs" -o "C:\Cases\%investigation%\Analysis\EventLogs\Hayabusa\Hayabusa_timeline.csv" --no-wizard > "C:\Cases\%investigation%\Analysis\EventLogs\Hayabusa\Hayabusa_output.txt"
::WxTCmd
echo Run WxTCmd to parse ActivitiesCache
cd "C:\Tools\EZTools"
WxTCmd.exe -f "C:\Cases\%investigation%\Kape\%disk%\Users\%useraccount%\AppData\Local\ConnectedDevicesPlatform\L.%useraccount%\ActivitiesCache.db" --csv "C:\Cases\%investigation%\Analysis\User_Activities\Cache"
:: LECmd
echo Run LECmd to parse Link files
cd "C:\Tools\EZTools"
LECmd.exe -d "C:\Cases\%investigation%\Kape\%disk%\Users\%useraccount%\AppData\Roaming\Microsoft\Windows\Recent" --csv "C:\Cases\%investigation%\Analysis\User_Activities\Link_Files"
:: JLECmd
echo Run LECmd to parse Jump lists
cd "C:\Tools\EZTools"
JLECmd.exe -d "C:\Cases\%investigation%\Kape\%disk%\Users\%useraccount%\AppData\Roaming\Microsoft\Windows\Recent" --csv "C:\Cases\%investigation%\Analysis\User_Activities\Jump_Lists"
:: Copy history of executed commands
echo Copy history of executed commands
cd /d "C:\"
xcopy "C:\Cases\%investigation%\Kape\%disk%\Users\%useraccount%\AppData\Roaming\Microsoft\Windows\PowerShell\PSReadline\ConsoleHost_history.txt" "C:\Cases\%investigation%\Analysis\User_Activities\" /H
echo Done!
set /p=Hit ENTER to continue...
timeout 5 > NUL
//TODO
While this batch script does the job well, I plan to convert it to PowerShell for better readability and control. I would also like to automate the image mounting for a fully automated workflow.
This script saves time before the triage and ensures consistency across forensic investigations. If you regularly analyze Windows disk images, a setup like this can significantly speed up your initial evidence collection.
Edit: Extended script to o.a. use Kape Modules and acquire device information using RegRipper. Edit: Moved Hayabusa from Kape to Hayabusa.exe
